High Performance Silicone Thermal Pad 1.0mmT Thermal Conductive Gap Filler Thermal Sheet For Unmanned Drone

Name: High Performance Silicone Thermal Pad 10mmT Thermal Conductive Gap Filler Thermal Sheet For Unmanned Drone
Brand: Ziitek
Price: 0.1 USD

China High Performance Silicone Thermal Pad 1.0mmT Thermal Conductive Gap Filler Thermal Sheet For Unmanned Drone wholesale

Brand Name : Ziitek

Model Number : TIF140-07E Series

Certification : UL & RoHS

Place of Origin : China

MOQ : 1000pcs

Price : 0.1-10 USD/PCS

Payment Terms : T/T

Supply Ability : 1000000 pcs/month

Delivery Time : 3-5 work days

Packaging Details : 24*13*12cm cartons

Product name : High Performance Silicone Thermal Pad 1.0mmT Thermal Conductive Gap Filler Thermal Sheet For Unmanned Drone

Thickness : 1.0mmT

Specific Gravity : 2.3g/cc

Dielectric Breakdown Voltage : >5500 VAC

Thermal conductivity : 1.5W/m-K

Color : Green

Keywords : Silicone thermal pad

Application : CPU / GPU,Unmanned Drone

Sample : Sample available

Contact Now

High Performance Silicone Thermal Pad 1.0mmT Thermal Conductive Gap Filler Thermal Sheet For Unmanned Drone

Company Profile

Ziitek company is a manufacturer of thermal conductive gap fillers, low melting point thermal interface materials, thermal conductive insulators, thermally conductive tapes, electrically & thermally conductive Interface pads and thermal grease,Thermal Conductive plastic,Silicone Rubber,Silicone Foams,Phase Changing Materials products, with well-equipped testing equipment and strong technical force.

Certifications:

ISO9001:2015

ISO14001: 2004 IATF16949:2016

IECQ QC 080000:2017

The TIF140-07E Series is not only designed to take advantage of the gap heat transfer, to fill gaps, complete the heat transfer between heating and cooling parts, but also played insulation, damping, sealing and so on, to meet the equipment miniaturization and ultra-thin design Requirements, which is a highly technology and use, and the thickness of the wide range of applications, is also an excellent thermal conductivity filler material.

High Performance Silicone Thermal Pad 1.0mmT Thermal Conductive Gap Filler Thermal Sheet For Unmanned Drone
Features

> Good thermal conductive: 1.5W/mK
> Available in varies thickness
> UL recognized
> Broad range of hardnesses available
> High tack surface reduces contact resistance

> Electrically isolating

Applications

> LED TV / LED Lit Lamps
> CD-Rom, DVD-Rom cooling
> SAD-DC Power Adapters
> CPU
> Memory Modules
> routers
> Telecommunication hardware

> mainboard/mother board

> IT infrastructure

> GPS navigation and other portable devices

Typical Properties of TIF140-07E Series
Property	Value	Test method
Color	Green	Visual
Construction & Compostion	Ceramic filled silicone elastomer	******
Density	2.3g/cm³	ASTM D297
Thickness range	0.020"(0.5mm)~0.200"(5.0mm)	******
Hardness	35 Shore 00	ASTM 2240
Continuos Use Temp	-45 to 200℃	*****
Dielectric Breakdown Voltage	>5500 VAC	ASTM D149
Dielectric Constant	4.7 MHz	ASTM D150
Volume Resistivity(Ohm-cm)	1.0X10¹²	ASTM D257
Fire rating	94 V0	UL equivalent
Thermal conductivity	1.5W/m-K	ASTM D5470

Standard Thicknesses:

0.020" (0.51mm) 0.030" (0.76mm)

0.040" (1.02mm) 0.050" (1.27mm) 0.060" (1.52mm)

0.070" (1.78mm) 0.080" (2.03mm) 0.090" (2.29mm)

0.100" (2.54mm) 0.110" (2.79mm) 0.120" (3.05mm)

0.130" (3.30mm) 0.140" (3.56mm) 0.150" (3.81mm)

0.160" (4.06mm) 0.170" (4.32mm) 0.180" (4.57mm)

0.190" (4.83mm) 0.200" (5.08mm)

Consult the factory to alternate thickness.

High Performance Silicone Thermal Pad 1.0mmT Thermal Conductive Gap Filler Thermal Sheet For Unmanned Drone

Packaging Details & Lead time

The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized

Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated
