1.0mmT Silicone Thermal Pad 1.8 W/MK 25shore00 For Telecommunication Hardware

Name: 10mmT Silicone Thermal Pad 18 WMK 25shore00 For Telecommunication Hardware
Brand: Ziitek
Price: 0.1 USD

China 1.0mmT Silicone Thermal Pad 1.8 W/MK 25shore00 For Telecommunication Hardware wholesale

Brand Name : Ziitek

Model Number : TIF540-18-11US thermal pad

Certification : UL

Place of Origin : China

MOQ : 1000 pcs

Price : 0.1-10 USD/PCS

Payment Terms : T/T

Supply Ability : 100000pcs/month

Delivery Time : 3-8 work days

Packaging Details : 25*24*13cm canton

hardness : 25shore00

KEYWORD : grey silicone rubber pads

color : grey

part number : TIF540-18-11US

material : silicone

thermal conductive : 1.8 W/mK

Contact Now

1.0mmT silicone thermal pad, Good thermal conductive 1.8 W/mK ,25shore00 for Telecommunication hardware

Company Profile

Ziitek Electronic Material and Technology Ltd. provides product solutions to equipment product which generates too much heat affecting its high performance when using. Plus thermal products can control and manage heat to keep it cool to some extent.

TIF500-18-11US Datasheet-REV02.pdf

The TIF540-18-11US is an electrically isolating material, which allows its use in applications requiring isolation between heat sinks and high-voltage, bare-leaded devices.

Features

<Good thermal conductive: 1.8 W/mK

<Thickness:1.0mmT

<Available in varies thicknesses

<Broad range of hardnesses available

<Easy release construction

<Electrically isolating

<Moldability for complex parts

<Soft and compressible for low stress applications

Applications

<Telecommunication hardware

<Handheld portable electronics

<Set top boxes

<Audio and video components

<Handheld portable electronics

<Semiconductor automated test equipment (ATE)

<LED Power Supply

<LED Controller

<LED Ceilinglamp

Typical Properties of TIF540-18-11US
Product Name	TIF540-18-11US Series
Colour	Grey
Construction & Compostion	Ceramic filled silicone rubber
Specific Gravity	2.8 g/cc
Dielectric Constant@1MHz	4.2 MHz
Hardness	20 Shore 00
Flame Rating	94 -V0
Continuos Use Temp	-40 to 160℃
Dielectric Breakdown Voltage	>5500 VAC
Thermal conductivity	1.8 W/mK
Thickness	1.0mmT

Peressure Sensitive Adhesive:

Request adhesive on one side with "A1" suffix.

Request adhesive on double side with "A2" suffix.

Reinforcement: TIF™ series sheets type can add with fiberglass reinforced.

Standard Sheets Sizes:

8" x 16"(203mm x 406mm)

TIF™ series Individual die cut shapes can be supplied.
