RoHS Compliant Thermally Conductive Pad Silicone Rubber 20shore00 For Electronics

Name: RoHS Compliant Thermally Conductive Pad Silicone Rubber 20shore00 For Electronics
Brand: Ziitek
Price: 0.1 USD

China RoHS Compliant Thermally Conductive Pad Silicone Rubber 20shore00 For Electronics wholesale

Brand Name : Ziitek

Model Number : TIF5180-50-11US thermal pad

Certification : UL

Place of Origin : China

MOQ : 1000 pcs

Price : 0.1-10 USD/PCS

Payment Terms : T/T

Supply Ability : 100000pcs/month

Delivery Time : 3-8 work days

Packaging Details : 25*24*13cm canton

hardness : 20shore00

KEYWORD : grey silicone rubber pads

color : grey

part number : TIF5180-50-11US

material : silicone

thermal conductive : 5.0W/m-k

Contact Now

4.5mmT RoHS compliant thermally conductive silicone rubber, ultra soft 20shore00 For Handheld portable electronics

Ziitek TIF5180-50-11US is recommended for applications that require a minimum amount of pressure on components. The viscoelastic nature of the material also gives excellent low-stress vibration dampening and shock absorbing characteristics. TIF5180-50-11US is an electrically isolating material, which allows its use in applications requiring isolation between heat sinks and high-voltage, bare-leaded devices.

TIF500-50-11US Datasheet-REV02.pdf

Company Profile

Ziitek Electronic Material and Technology Ltd. provides product solutions to equipment product which generates too much heat affecting its high performance when using. Plus thermal products can control and manage heat to keep it cool to some extent.

Features

<Good thermal conductive:5.0W/m-k

<Thickness:4.5mmT

<UL recognized

<RoHS compliant

<Electrically isolating

Applications

<High speed mass storage drives

<Telecommunication hardware

<Handheld portable electronics

<Set top boxes

<Audio and video components

Typical Properties of TIF 5180-50-11US
Product Name	TIF5180-50-11US Series
Colour	Grey
Construction & Compostion	Ceramic filled silicone rubber
Specific Gravity	3.0g/cc
Dielectric Constant@1MHz	4.0 MHz
Hardness	20 Shore 00
Flame Rating	94 -V0
Continuos Use Temp	-40to 160℃
Dielectric Breakdown Voltage	>5500 VAC
Thermal conductivity	5.0 W/mK
Thickness	4.5mmT

Packaging Details & Lead time

The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized

Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated

RoHS Compliant Thermally Conductive Pad Silicone Rubber 20shore00 For Electronics

Advantage

Ziitek has independent R&D team. This team is experience, rigorous and pragmatic.

They undertake the core research and development tasks of Ziitek thermal conductive materials. With well-equipped testing equipment, we Ziitek can also do some tests with customers' samples, so we can find a more suitable Ziitek materials for every customer.

Certifications:

ISO9001:2015

ISO14001: 2004 IATF16949:2016

IECQ QC 080000:2017
