3.0W/MK Silicone Thermal Pad 27shore00 For Heat Pipe Thermal Solutions

Name: 30WMK Silicone Thermal Pad 27shore00 For Heat Pipe Thermal Solutions
Brand: Ziitek
Price: 0.1 USD

China 3.0W/MK Silicone Thermal Pad 27shore00 For Heat Pipe Thermal Solutions wholesale

Brand Name : Ziitek

Model Number : TIF5140-30-11U thermal pad

Certification : UL

Place of Origin : China

MOQ : 1000 pcs

Price : 0.1-10 USD/PCS

Payment Terms : T/T

Supply Ability : 100000pcs/month

Delivery Time : 3-8 work days

Packaging Details : 25*24*13cm canton

hardness : 27shore00

KEYWORD : grey silicone rubber pads

color : grey

part number : TIF5140-30-11U

material : silicone

Thickness : 3.5mmT

Contact Now

3.0W/mK high cost-effective silicone thermal pad 27shore00 For Heat pipe thermal solutions

Company Profile

Ziitek Electronic Material and Technology Ltd. provides product solutions to equipment product which generates too much heat affecting its high performance when using. Plus thermal products can control and manage heat to keep it cool to some extent.

TIF500-30-11U Datasheet-REV02.pdf

The TIF5140-30-11U is a highly compliant Gap Pad material that is ideal for fragile component leads. The material is fiberglass reinforced for improved puncture resistance and handling TIF5140-30-11U maintains a conformable, yet elastic nature that provides excellent interfacing and wet-out characteristics, even to surfaces with high roughness or uneven topography. TIF5140-30-11U features an inherent tack on both sides of the material, eliminating the need for thermally impeding adhesive layers.Options and ConfigurationsStandard sheet size - 8" x 16" or custom configurationStandard thickness available - 0.020", 0.040", 0.060", 0.080", 0.100", 0.125", 0.160", 0.200", 0.250"Custom made configurations available upon request

Features

<Broad range of hardnesses available 3.0W/mK

<Thickness:3.5mmT

<RoHS compliant

<UL recognized

<Electrically isolating

Applications

<Heat pipe thermal solutions

<Memory Modules

<Automotive engine control units

<Telecommunication hardware

<LED Power Supply

<LED Controller

Typical Properties of TIF 5140-30-11U
Product Name	TIF5140-30-11U Series
Colour	Grey
Construction & Compostion	Ceramic filled silicone rubber
Specific Gravity	3.0g/cc
Dielectric Constant@1MHz	4.4 MHz
Hardness	27Shore 00
Flame Rating	94 -V0
Continuos Use Temp	-40to 160℃
Dielectric Breakdown Voltage	>5500 VAC
Thermal conductivity	3.0 W/mK
Thickness	3.5mmT

Certifications:

ISO9001:2015

ISO14001: 2004 IATF16949:2016

IECQ QC 080000:2017

Standard Sheets Sizes:

8" x 16"(203mm x 406mm)

TIF™ series Individual die cut shapes can be supplied.

3.0W/MK Silicone Thermal Pad 27shore00 For Heat Pipe Thermal Solutions

Advantage

Ziitek has independent R&D team. This team is experience, rigorous and pragmatic.

They undertake the core research and development tasks of Ziitek thermal conductive materials. With well-equipped testing equipment, we Ziitek can also do some tests with customers' samples, so we can find a more suitable Ziitek materials for every customer.
