3.5mmt 3 W Mk Thermal Pad Silicone For Mother Board

Name: 35mmt 3 W Mk Thermal Pad Silicone For Mother Board
Brand: Ziitek
Price: 0.1 USD

China 3.5mmt 3 W Mk Thermal Pad Silicone For Mother Board wholesale

Brand Name : Ziitek

Model Number : TIF1140-30-06US thermal pad

Certification : UL

Place of Origin : China

MOQ : 1000 pcs

Price : 0.1-10 USD/PCS

Payment Terms : T/T

Supply Ability : 100000pcs/month

Delivery Time : 3-8 work days

Packaging Details : 25*24*13cm canton

hardness : 18 shore00

KEYWORD : white silicone rubber pads

color : white

part number : TIF1140-30-06US

material : silicone

thermal conductive : 3.0W/mK

Contact Now

factory supply Good thermal conductive Electrically isolating thermal gap pad for mother board,3.5mmT

Company Profile

Ziitek company is a high-tech enterprise which dedicated to the R&D, manufacture and sales of the thermal interface materials (TIMs). We have rich experiences in this field which can support you the latest, most effective and one -step thermal management solutions. We have many advanced production equipments,full test equipments and fully automatic coating production lines which can support the production for high performance thermal silicone pad, thermal graphite sheet/ film, thermal double-sided tape, thermal insulation pad, thermal ceramic pad, phase change material, thermal grease etc. UL94 V-0, SGS and ROHS are compliant.

TIF100-30-06US.pdf

TIF1140-30-06US use a special process, with silicone as the base material, adding thermal conductive powder and flame retardant together to make the mixture to become thermal interface material. This is effective in lower the thermal resistance between the heat source and the heat sink.

<Good thermal conductive:3.0W/mK

<Thickness:3.5mmT

<Hardness:18 Shore 00

<Colour: white

<Naturally tacky needing no further adhesive coating

<Available in varies thicknesses

<Broad range of hardnesses available

Applications

<LED Power Supply

<LED Controller

<LED Ceilinglamp

<Monitoring the Power Box

<AD-DC Power Adapters

<Rainproof LED Power

Typical Properties of TIF1140-30-06US
Product Name	TIF1140-30-06US Series
Colour	white
Construction & Compostion	Ceramic filled silicone elastomer
Specific gravity	3.0 g/cc
Thickness	3.5mmT
Hardness	18 Shore 00
Dielectric constant@1MHz	4.0 MHz
Continuos Use Temp	-40to 160℃
Dielectric Breakdown Voltage	>5500 VAC
Thermal conductivity	3.0 W/mK
Volume Resistiviyt	1.0*10^{12 _Ohm-cm}

Standard Sheets Sizes:

8" x 16"(203mm x 406mm)

TIF™ series Individual die cut shapes can be supplied.

3.5mmt 3 W Mk Thermal Pad Silicone For Mother Board

Our services

Online-service : 12 hours , Inquiry reply within fastest.

Working time: 8:00am - 5:30pm, Monday to Saturday (UTC+8).

Well-trained & experienced staff are to answer all your inquiries in English of course.

Standard Export Carton Or Marked With Customer's Information Or Customized.

Provide free samples

After-service: Even our products have passed strict inspection, if you find the parts can not work well, please show us the proof.

we will help you to deal with it and give you satisfactory solution.

3.5mmt 3 W Mk Thermal Pad Silicone For Mother Board

FAQ

Q:Do big buyers have promotional prices?

A: Yes, if you are a big buyer in a certain area, Ziitek will provide you with promotional prices, which will help you start your business here. Buyers with long-term cooperation will have better prices.

Q:Is there promotion price for big buyer?

A:Yes, we do have promotion price for big buyer. Please send us email for inquiry.
