3.15g/Cm3 No Further Adhesive Coating Cpu Thermal Pad Silicone

Name: 315gCm3 No Further Adhesive Coating Cpu Thermal Pad Silicone
Brand: Ziitek
Price: 0.1 USD

China 3.15g/Cm3 No Further Adhesive Coating Cpu Thermal Pad Silicone wholesale

Brand Name : Ziitek

Model Number : TIF1100-40-11US thermal pad

Certification : UL

Place of Origin : China

MOQ : 1000 pcs

Price : 0.1-10 USD/PCS

Payment Terms : T/T

Supply Ability : 100000pcs/month

Delivery Time : 3-8 work days

Packaging Details : 25*24*13cm canton

Density : 3.15g/cm3

Color : gray

Volume Resistiviyt : 6.0*1012 Ohm-cm

thermal conductive : 4.0W/mK

hardness : 20 shore00

name : No Further Adhesive Coating Cpu Thermal Pad Silicone 3.15g/Cm3

Contact Now

Naturally tacky needing no further adhesive coating silicone pads for CPU

Company Profile

Ziitek Electronic Material and Technology Ltd. is a R&D and production company, we have many production lines and processing technology of thermal conductive materials, owns advanced production equipment and optimized process, can provide various thermal solutions for different applications.

TIF100-40-11US-Series-Datasheet.pdf

TIF1100-40-11US is a silicone based, thermally conductive gap pad. Its unreinforced construction allows additional compliancy. This product has low hardness is conformable and is electrically isolating. The low modulus characteristic of the product offers optimal thermal performance with the ease of handling.

<Good thermal conductive:4.0W/mK

<Thickness:2.5mmT

<Hardness:20 Shore 00

<Colour: gray

<Moldability for complex parts

<Soft and compressible for low stress applications

<Naturally tacky needing no further adhesive coating

Applications

<Waterproof LED Power

<SMD LED module

<LED Flesible strip, LED bar

<LED PanelLight

<LED floor light

<Routers

Typical Properties of TIF1100-40-11US
Product Name	TIF1100-40-11US Series
Colour	gray
Construction & Compostion	Ceramic filled silicone elastomer
Specific gravity	3.15 g/cc
Thickness	2.5mmT
Hardness	20 Shore 00
Dielectric constant@1MHz	4.0 MHz
Continuos Use Temp	-40to 160℃
Dielectric Breakdown Voltage	>5500 VAC
Thermal conductivity	4.0 W/mK
Volume Resistiviyt	6.0*10^{12 _Ohm-cm}

Standard Sheets Sizes:

8" x 16"(203mm x 406mm)

TIF™ series Individual die cut shapes can be supplied.

3.15g/Cm3 No Further Adhesive Coating Cpu Thermal Pad Silicone

Ziitek Culture

Quality :

Do it right the first time, total quality control

Effectiveness:

Work precisely and thoroughly for effectiveness

Service:

Quick response, On time delivery and Excellent service

Team work:

Complete teamwork, including sales team, Marketing team, engineering team, R&D team, Manufacturing team, logistics team. All is for supporting and servicing a satisfy service for customers.

3.15g/Cm3 No Further Adhesive Coating Cpu Thermal Pad Silicone

FAQ

Q: How much are the pads?

A: Price is depended on your size, thickness, quantity, and other requirements, such as adhesive and others. Please let us know these factors first so that we could give you an exact price.
