Pink / White Outstanding Thermal Performance Thermal Pad for RDRAM Memory Modules

Name: Pink White Outstanding Thermal Performance Thermal Pad for RDRAM Memory Modules
Brand: Ziitek
Price: 0.1 USD

China Pink / White Outstanding Thermal Performance Thermal Pad for RDRAM Memory Modules wholesale

Brand Name : Ziitek

Model Number : TIF2160-20-02ES thermal pad

Certification : UL

Place of Origin : China

MOQ : 1000 pcs

Price : 0.1-10 USD/PCS

Payment Terms : T/T

Supply Ability : 100000pcs/month

Delivery Time : 3-8 work days

Packaging Details : 25*24*13cm canton

Name : Pink/White Outstanding Thermal Performance Thermal Pad for RDRAM Memory Modules

Application : CPU

Dielectric Breakdown Voltage : >5000 VAC

keyword : Thermal Gap Pad

Flame Rating : 94-V0

thermal conductive : 2.0 W/mK

Contact Now

Pink/White Outstanding Thermal Performance Thermal Pad for RDRAM Memory Modules

Company Profile

With a wide range, good quality, reasonable prices and stylish designs, Ziitek thermal conductive interface materials are extensively used in Mainboards, VGA cards, Notebooks, DDR&DDR2 products, CD-ROM ,LCD TV, PDP products, Server Power products, Down lamps, Spotlights, Street lamps, Daylight lamps, LED Server Power products and others.

TIF200-20-02ES-Series-Datasheet.pdf

Ziitek TIF2160-20-02ES is a silicone based, thermally conductive gap pad. Its unreinforced construction allows additional compliancy. This product has low hardness is conformable and is electrically isolating. The low modulus characteristic of the product offers optimal thermal performance with the ease of handling.

<Good thermal conductive: 2.0 W/mK

<Thickness: 4.0mmT

<Hardness:10 Shore 00

<Colour: Pink/White

<Moldability for complex parts
<Outstanding thermal performance
<High tack surface reduces contact resistance

Applications

<cooling components to the chassis of frame

<High speed mass storage drives

<Heat Sinking Housing at LED-lit BLU in LCD

<LED TV and LED-lit lamps

<RDRAM memory modules

<Micro heat pipe thermal solutions

Typical Properties of TIF2160-20-02ES
Product Name	TIF2160-20-02ES Series
Colour	Pink/White
Construction & Compostion	Ceramic filled silicone elastomer
Specific gravity	2.8 g/cm^3
Thickness	4.0mmT
Hardness	10 Shore 00
Dielectric constant@1MHz	5.0 MHz
Continuos Use Temp	-40 to 160℃
Dielectric Breakdown Voltage	>5000 VAC
Thermal conductivity	2.0W/mK
Flame Rating	94-V0

Standard Sheets Sizes:

8" x 16"(203mm x 406mm)

TIF™ series Individual die cut shapes can be supplied.

Pink / White Outstanding Thermal Performance Thermal Pad for RDRAM Memory Modules

Why Choose us ?

1.Our value message is'' Do it right the First time, total quality control''.

2.Our core competencies is thermal conductive interface materials

3.Competitive advantage products.

4.Condidentiality agreement Bussiness Secrect Contract

5.Free sample offer

6.Quality assurance contract

Pink / White Outstanding Thermal Performance Thermal Pad for RDRAM Memory Modules

FAQ

Q: How do I place an order?

A:1. Click the "Sent messages" button to continue with the process.

2. Fill out the message form by entering a subject line, and message to us.

This message should include any questions you might have about the products as well as your purchase requests.

3. Click the "Send" button when you are finished to complete the process and send your message to us

4. We will reply you as soon as possible with Email or online
