Ziitek company is a manufacturer of thermal conductive gap fillers, low melting point thermal interface materials, thermal conductive insulators, thermally conductive tapes, electrically & thermally conductive Interface pads and thermal grease,Thermal Conductive plastic,Silicone Rubber,Silicone Foams,Phase Changing Materials products, with well-equipped testing equipment and strong technical force.
TIF700PES-(TDS-EN-REV04).pdf
Ziitek TIF7120PES is an extremely soft gap filling material rated at a thermal conductivity of 7.5W/m-K. It is specially formulated for high performance applications requiring low assembly stress. The material offers exceptional thermal performance at low pressures due to the unique filler package and ultra low modulus resin formulation. Ziitek TIF7120PES is highly conformal to rough or irregular surfaces, allowing excellent wet-out at the interface. Protective liners are supplied on both sides allowing for ease of use.
| Typical Properties of TIF7120PES |
| Product Name | TIF7120PES Series |
| Colour | Gray |
| Construction & Compostion | Ceramic filled silicone elastomer |
| Specific gravity | 3.2 g/cc |
| Thickness | 3.0mmT |
| Hardness(Shore 00) | 10 |
| Dielectric constant@1MHz | 5~6 MHz |
| Continuos Use Temp | -40 to 160℃ |
| Dielectric Breakdown Voltage | >5000 VAC |
| Thermal conductivity | 7.5W/mK |
| Flame Rating(no.E331100) | V-0 |
Packaging Details & Lead time
The packaging of thermal pad
1.with PET film or foam-for protection
2. use Paper Card To Separate Each Layer
3. export carton inside and outside
4. meet with customers' requirement-customized
Lead Time :Quantity(Pieces):5000
Est. Time(days): To be negotiated
