Ideal Material Cut Into Any Shape Non-Toxic Thermal Pad For Medical Devices

Name: Ideal Material Cut Into Any Shape NonToxic Thermal Pad For Medical Devices
Brand: Ziitek
Price: 0.1 USD

China Ideal Material Cut Into Any Shape Non-Toxic Thermal Pad For Medical Devices wholesale

Brand Name : Ziitek

Model Number : TIF400 Series

Certification : UL & RoHS

Place of Origin : China

MOQ : 1000pcs

Price : 0.1-10 USD/PCS

Payment Terms : T/T

Supply Ability : 1000000 pcs/month

Delivery Time : 7-10 work days

Packaging Details : 24*13*12cm cartons

Products name : Ideal Material Cut Into Any Shape Non-Toxic Thermal Pad For Medical Devices

Thickness range : 0.5mm~5.0mm(0.02"~0.2")

Specific Gravity : 2.65g/cc

Dielectric Breakdown Voltage : ≥5500 VAC

Thermal conductivity : 2.0W/m-K

Color : Yellow

Materials : Ceramic filled silicone elastomer

Operating temp : -45~200℃

Keywords : Silicone Thermal Pad

Contact Now

Ideal Material Cut Into Any Shape Non-Toxic Thermal Pad For Medical Devices

The TIF™400 Series thermal silicone pad is a product with both performance and economy. It is a unique thermal pad with low oil permeability, low thermal resistance, high softness and high compliance.It can work stably at -45℃~200℃ and meet the requirement of UL94V0.

Ideal Material Cut Into Any Shape Non-Toxic Thermal Pad For Medical Devices
Features
> Good thermal conductive: 2.0W/mK
> Available in varies thickness
> UL recognized
> Broad range of hardnesses available
> High tack surface reduces contact resistance

> Electrically isolating

Applications
> Rainproof LED Power
> Display card
> Mainboard/mother board
> Notebook
> Power supply
> Heat pipe thermal solutions
> Memory Modules
> Medical Devices

Typical Properties of TIF™480 Series
Color	Yellow	Visual
Construction &Compostion	Ceramic filled silicone elastomer
Thinkness range	0.020"(0.50mm~0.200"(5.0mm)	ASTM D374
Hardness	45 Shore 00	ASTM 2240
Specific Gravity	2.65 g/cc	ASTM D297
Continuos Use Temp	-45-200℃
Dielectric BreakdownVoltage @ 1.0mm,AC(v)	≥5500	ASTM D149
Dielectric Constant @MHz	4.7	ASTM D150
Volume Resistivity(Ohm-cm)	≥5.3X10¹² Ohm-meter	ASTM D257
Thermal conductivity	2.0 W/m-K	ASTM D5470
Fire rating	94 V-0	UL E331100
Application	Medical Devices
Place of Origin	Guandong,China
Cetification	ROHS,UL
Sample	Samlpe valiable
Size	Customized size

Product Thicknesses:

0.020-inch to 0.200-inch (0.5mm to 5.0mm)

Product Sizes:

8"x 16"(203mm x406mm)

Individual die cut shapesand and custom thickness can be supplied.

Please contact us for confirming

Peressure Sensitive Adhesive:
Request adhesive on one side with "A1" suffix.
Request adhesive on double side with "A2" suffix.

Reinforcement:
TIF™ series sheets type can add with fiberglass reinforced.

Ideal Material Cut Into Any Shape Non-Toxic Thermal Pad For Medical Devices

Packaging Details & Lead time

The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized

Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated

Company Profile

With professional R&D capabilities and over 19 year experiences in thermal interface material industry, Ziitek company own many unique formulations which are our core technologies and advantages. Our goal is to provide quality & competitive products to our customers worldwide aiming for long-term business cooperation.

Certifications:

ISO9001:2015

ISO14001: 2004 IATF16949:2016

IECQ QC 080000:2017

Independent R&D team
