Ultra Soft 2.5mm CPU Thermal Pad 8.0W For Battery Pack RoHS and UL Certification

Name: Ultra Soft 25mm CPU Thermal Pad 80W For Battery Pack RoHS and UL Certification
Brand: Ziitek
Price: 0.1 USD

China Ultra Soft 2.5mm CPU Thermal Pad 8.0W For Battery Pack RoHS and UL Certification wholesale

Brand Name : Ziitek

Model Number : TIF7100QE

Certification : RoHS and UL recognized

Place of Origin : China

MOQ : 1000pcs

Price : 0.1-10 USD/PCS

Payment Terms : T/T

Supply Ability : 1000000 pcs/month

Delivery Time : 3-5 work days

Packaging Details : 24*13*12cm cartons

Products name : Ultra Soft 2.5mm CPU Thermal Pad 8.0W For Battery Pack

Keywords : CPU Thermal Pad

Thinkness range : 2.5mmT

Sample : Sample Avaliable

Flam rating : 94 V0

Hardness : 35±10 Shore 00

Thermal Conductivity : 8.0 W/mK

Color : Gray

Contact Now

Ultra Soft 2.5mm CPU Thermal Pad 8.0W For Battery Pack

Company Profile

Ziitek company is a high-tech enterprise which dedicated to the R&D, manufacture and sales of the thermal interface materials (TIMs). We have rich experiences in this field which can support you the latest, most effective and one -step thermal management solutions. We have many advanced production equipments,full test equipments and fully automatic coating production lines which can support the production for high performance thermal silicone pad, thermal graphite sheet/ film, thermal double-sided tape, thermal insulation pad, thermal ceramic pad, phase change material, thermal grease etc. UL94 V-0, SGS and ROHS are compliant.

Certifications:

ISO9001:2015

ISO14001: 2004 IATF16949:2016

IECQ QC 080000:2017

TIF7100QE thermal silicone pad is a product with both performance and economy. It is a unique thermal pad with low oil permeability, low thermal resistance, high softness and high compliance.It can work stably at -45℃~200℃ and meet the requirement of UL94V0.

Ultra Soft 2.5mm CPU Thermal Pad 8.0W For Battery Pack RoHS and UL Certification

Features

> Good thermal conductive : 8.0W/mK
> Soft and Compressible for low stressapplications
> High tack surface reduces contact resistance
> RoHS compliant
> UL recognized
> Naturally tacky needing no further adhesive coating
> Available in varies thicknesses
> Broad range of hardnesses available
> Moldability for complex parts

Applications

> Set top boxes
> Audio and video components
> CPU
> Display card
> Mainboard/mother board
> Notebook
> Set top boxes
> Audio and video components
> IT infrastructure
> GPS navigation and other portable devices

Typical Properties of TIF7100QE Series
Color	Gray	Visual
Construction & Compostion	Ceramic filled silicone elastomer	*******
Specific Gravity	3.5g/cc	ASTM D297
Thickness range	2.5mm	ASTM C351
Hardness	35±10 Shore 00	ASTM 2240
Dielectric Breakdown Voltage	>5500 VAC	ASTM D412
Operating Temp	-45 ~200℃	*******
Dielectric Constant	5.5 MHz	ASTM D150
Volume Resistivity	1.0X10¹²Ohm-meter	ASTM D257
Fire rating	94 V0	equivalent UL
Thermal conductivity	8.0W/mK	ASTM D5470

Standard Thicknesses:

0.020" (0.51mm) 0.030" (0.76mm)

0.040" (1.02mm) 0.050" (1.27mm) 0.060" (1.52mm)

0.070" (1.78mm) 0.080" (2.03mm) 0.090" (2.29mm)

0.100" (2.54mm) 0.110" (2.79mm) 0.120" (3.05mm)

0.130" (3.30mm) 0.140" (3.56mm) 0.150" (3.81mm)

0.160" (4.06mm) 0.170" (4.32mm) 0.180" (4.57mm)

0.190" (4.83mm) 0.200" (5.08mm)

Consult the factory to alternate thickness.

Standard Sheets Sizes:

8" x 16"(203mm x 406mm)

Individual die cut shapes and custom thickness can be supplied.

Ultra Soft 2.5mm CPU Thermal Pad 8.0W For Battery Pack RoHS and UL Certification

Packaging Details & Lead time

The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized

Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated.

FAQ:

Q: Are you trading company or manufacturer ?

A: We are manufacturer in China.

Q: How long is your delivery time?

A: Generally it is 3-7 work days if the goods are in stock. or it is 7-10 work days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra cost?

A: Yes, we could offer samples free of charge.
